Physical Characteteristics:

Dimensions: 350mm x 300mm x 104mm

Weight: approx 3.0kg

Display Specifications:

Display: 5.6 inches color TFT-LCD Resolution: RGB 640 (W) x (480 (H)

Ultrasound:

Technique: Ultrasound Pulse Doppler with autocorrelation Pulse repetition rate: 2 Khz Pulse Duration: 92 ps Ultrasound frequency: 1.0 Mhz±10% FHR Measurement range: 50bpm– 240bpm FHR Resolution: 1bpm FHR Accuracy: ±1 bpm

TOCO:

Measurement range: 0-100% Resolution: 1% Zero Mode: Auto / Manual Non-linear error: 10% DECG:

Techinque: Peak – Peak detection technique DFHR Measurement range: 30bpm–240bpm Resolution: 1bpm

Accuracy: ±1bpm Input Impedance: > 10M (Differential), >20M (Commaon Mode) IUP:

Measurement range: 0 mmHg –100 mmHg Resolution: 1% Zero Mode: Auotmatic/Manual Auto Fetal Movement:

Technique: Pulse Doppler ultrasound Measurement Range: 0% ~ 100% Resolution: 1%

Manual Fetal Movement:

Method: Remote marker

Recorder:

Recorder Type: Thermol printer Recorder Paper: Z-fold thermosensitive (150 mm) Real Time Printing Speed: 1/2/3 cm/min Stored Traces Printing Speed: Up to 15 mm/sec Resolution: 8 dots/mm Record information: FHR1 traces, FHR2 traces, TOCO trace, AFM  trace, fetal movement mark, event mark, AUTO-zero symbol, date, time, printing speed, ID, name FHR2 Offset, etc.

Power Supply:  Operating Voltage: 100V – 240V
